12V 2W LTE Signal Amplifier , 902MHz 928MHz Network Signal Booster
  • 12V 2W LTE Signal Amplifier , 902MHz 928MHz Network Signal Booster
  • 12V 2W LTE Signal Amplifier , 902MHz 928MHz Network Signal Booster
  • 12V 2W LTE Signal Amplifier , 902MHz 928MHz Network Signal Booster
  • 12V 2W LTE Signal Amplifier , 902MHz 928MHz Network Signal Booster
  • 12V 2W LTE Signal Amplifier , 902MHz 928MHz Network Signal Booster

12V 2W LTE Signal Amplifier , 902MHz 928MHz Network Signal Booster

Place of Origin China
Brand Name MXT
Model Number TDD902T928M 2W-12V
Product Details
Output Power:
≥33dBm
Gain:
≥13dB
Efficiency:
>10%
Input/Output VSWR:
<1.8
Temperature Range:
-20~+65℃
Input Power:
-10dBm~ 0dBm
Frequency Range:
902MHz-928MHz
Size:
75*45*25mm
High Light:

12V LTE Signal Amplifier

,

2W LTE Signal Amplifier

,

928MHz Network Signal Booster

Payment & Shipping Terms
Minimum Order Quantity
2
Price
Negotiable
Delivery Time
30 Work Days
Payment Terms
L/C, T/T
Supply Ability
500Sets 30 Days
Product Description

2W COFDM Signal Booster Video Link Transmit 12V DC Supply 902MHz 928MHz TD LTE Mode

Product Description:

LTE Power Amplifier

This reliable LTE Power Amplifier features an aluminium case, which provides excellent protection to the device and ensures longevity. It boasts a temperature range of -20℃ to +65℃ and has an output power of more than 33dBm. Additionally, the amplifier has a gain of more than 38dB and an efficiency of more than 15%. Moreover, it has an input/output VSWR of less than 1.8. The amplifier has a compact design with an IPEX socket at the input and an MCX socket at the output, and comes with a heat sink for increased stability over long operating hours





Features:

  • Product Name: LTE Power Amplifier
  • Output Power: >33dBm
  • Power Supply: 12V (support 9-15V)
  • Frequency Range: 902MHz -928MHz
  • Gain: >13dB
  • Noise Figure: <3dB
  • Application: Support high-speed data transmission, video links and long-distance data transmission.


Technical Parameters:

Item Specification
Frequency Range 902-928MHz (or Customized)
Output Power 33dBm
Tx Gain 13 ± 1 (dB)
Rx Gain 13 ± 1 (dB)
Gain Flatness 1.0 (dB) Peak To Peak Over Freq Band
EVM ≤3.5%
Noise Figure ≤3.0(dB)
In/Out VSWR Less Than 1.8:1
DC Current 1 (A) @12V
Size(DxWxH) 75*45*25 (mm)
In/Out Commector IPEX/MCX
Time Delay ≤2(us)
Operation Temp. -20 ~ +65 (°C)
I/O Map
Socket 1x3Pin 2.54mm
Pin 1:PA_EN
Pin 2:GND
Pin 3:12V
Supply Voltage 12V
Work Mode TDD OFDM Signal





Applications:

MXT LTE Power Amplifier is designed with a frequency range of 902MHz-928MHz, noise figure of less than 3dB, input/ output VSWR of less than 1.8, and gain of more than 17dB. Its size is 75*45*25mm, and it is known for its high linearity, ACPR up to 41dBc, and efficiency up to 10%. It is an ideal choice for applications such as P to P networking and other wireless communication systems.



Customization:

MXT's LTE Power Amplifier offers a customised service with a video link to ensure customers get the best product for their needs. This amplifier is made from an aluminium case, making it lightweight and durable, perfect for any TD LTE application. It offers an efficiency of >10%, a noise figure of <3dB, an input/output VSWR of <1.8, an input power of 18dBm to 20dBm, and a gain of >13dB. Customers are sure to receive the highest quality experience with MXT's LTE Power Amplifier.



Support and Services:

RF Power Amplifier Technical Support & Services

We offer technical support and services for our RF Power Amplifier products to ensure that they are functioning properly and providing the best possible performance.

Installation & Setup

We are available to provide assistance with the installation and setup of your RF Power Amplifier. Our team of experienced engineers can guide you through the process and answer any questions you have.

Troubleshooting

If you are experiencing any issues with your RF Power Amplifier, our team of experts can help identify the source of the problem and provide you with solutions to resolve it quickly.



FAQ:

Q1. Could I get a sample before bulk order?
Yes, we offer the sample for all models but charged.

Q2. What should I do if I don't know about frequency in my country?
Please feel free to contact us with your inquiry, we will find the frequency you need and address your problems.

Q3. Do you accept OEM / ODM order?
Yes, we can customize the brand logo, colors, and frequencies.

Q4. Delivery & Shipment Date:
5-30 days

Q5. Customized Frequency:
We can customize Single/Double/Triple/Quand/Penta Band for cellphone signal like 2G/3G/4G(GSM/CDMA/DCS/PCS/WCDMA/LTE, etc,)

We provide technical support and services for our LTE Power Amplifier product. Our technical support staff is available 24/7 to help with any issues that you may encounter. We have a comprehensive range of technical services available, including troubleshooting, installation, and maintenance. We also offer regular software and firmware updates to ensure your product is always up to date. If you ever have any questions or concerns, our experienced team is available to provide the help and support you need.
